The ROG Xbox Ally (2025) combines console-caliber AMD performance and long battery life with seamless Xbox + PC gaming, all wrapped in an ergonomic, high-refresh handheld design.
The ROG Xbox Ally is powered by the ultra-efficient AMD Ryzen Z2 A processor and a 60 Wh battery, enabling high performance and long playtime on the go.
With the Xbox Full Screen Experience on Windows 11, users can jump straight into their Xbox library, stream via Xbox Cloud Gaming, or run native PC titles — all from one device
*
Operating System
Windows 11 Home
Processor
CPU: AMD Ryzen™ Z2 A Processor 2.8GHz (6MB Cache, up to 3.8 GHz, 4 cores, 8 Threads)
GPU: AMD Radeon™ Graphics
Display
7-inch
FHD (1920 x 1080) 16:9
IPS-level
Glossy display
sRGB: 100%
Adobe: 75.35%
Gorilla® Glass Victus™
Gorilla® Glass DXC
Touch Screen (10-point multi-touch)
Refresh Rate: 120Hz
Brightness: 500 nits
AMD FreeSync™ Premium (Variable Refresh Rate)
Memory
16GB LPDDR5 on board (6400MT/s dual channel)
Support dual channel memory
Storage
512GB PCIe® 4.0 NVMe™ M.2 SSD (2280)
I/O Ports
1x 3.5mm Combo Audio Jack
2x USB 3.2 Gen 2 Type-C support DisplayPort™ / power delivery
1x UHS-II microSD card reader (supports SD, SDXC and SDHC)
Control and Input
View button
Menu button
L & R Hall Effect analog triggers
L & R bumpers
D-pad
Command Center button
Armoury Crate button
A B X Y buttons
2 x assignable grip buttons
Thumbsticks: 2 x full-size analog sticks
Haptics: HD haptics
Gyro: 6-Axis IMU
Audio
Smart Amp Technology
Hi-Res certification (for headphone)
Dolby Atmos
AI noise-canceling technology
Built-in array microphone
2-speaker system with Smart Amplifier Technology
Network and Communication
Wi-Fi 6E(802.11ax) (Triple band) 2*2 + Bluetooth® 5.2 (*Bluetooth® version may change with OS version different.)
Battery
60WHrs, 4S1P, 4-cell Li-ion
Power Supply
TYPE-C, 65W AC Adapter, Output: 20V DC, 3.25A, 65W, Input: 100~240V AC 50/60Hz universal
Dimensions (W x D x H)
29.0 x 12.1 x 2.75 ~ 5.09 cm (11.42" x 4.76" x 1.08" ~ 2.00")
Security
Microsoft Pluton security processor
Built-in Fingerprint Sensor
