The ROG Xbox Ally (2025) pairs high-end AMD processor power and long battery life with seamless Xbox + PC gaming in a comfortable, immersive handheld form.
Powered by the AMD Ryzen Z2 A processor and a 60 Wh battery, the ROG Xbox Ally delivers high-performance gaming and extended playtime away from the wall.
With the Xbox Full Screen Experience on Windows 11, you can instantly dive into your Xbox library, stream from the cloud, and run PC games — all from one handheld device
*
Operating System
Windows 11 Home
Processor
CPU: AMD Ryzen™ AI Z2 Extreme Processor 2.0GHz (24MB Cache, up to 5.0GHz, 8 cores, 16 Threads); AMD XDNA™ NPU up to 50TOPS
GPU: AMD Radeon™ Graphics
Display
7-inch
FHD (1920 x 1080) 16:9
IPS-level
Glossy display
sRGB: 100%
Adobe: 75.35%
Gorilla® Glass Victus™
Gorilla® Glass DXC
Touch Screen (10-point multi-touch)
Refresh Rate: 120Hz
Brightness: 500 nits
AMD FreeSync™ Premium (Variable Refresh Rate)
Memory
24GB LPDDR5X on board
Support dual channel memory
Storage
1TB PCIe® 4.0 NVMe™ M.2 SSD (2280)
I/O Ports
1x 3.5mm Combo Audio Jack
1x USB 3.2 Gen 2 Type-C support DisplayPort™ / power delivery
1x Type C support USB 4 (Thunderbolt™ 4 compliance, DisplayPort™ 1.4 with Freesync support, Power Delivery 3.0)
1x UHS-II microSD card reader (supports SD, SDXC and SDHC)
Control and Input
View button
Menu button
L & R Hall Effect analog triggers
L & R bumpers
D-pad
Command Center button
Armoury Crate button
A B X Y buttons
2 x assignable grip buttons
Thumbsticks: 2 x full-size analog sticks
Haptics: HD haptics
Gyro: 6-Axis IMU
Audio
Smart Amp Technology
Hi-Res certification (for headphone)
Dolby Atmos
AI noise-canceling technology
Built-in array microphone
2-speaker system with Smart Amplifier Technology
Network and Communication
Wi-Fi 6E(802.11ax) (Triple band) 2*2 + Bluetooth® 5.2 (*Bluetooth® version may change with OS version different.)
Battery
80WHrs, 4S1P, 4-cell Li-ion
Power Supply
TYPE-C, 65W AC Adapter, Output: 20V DC, 3.25A, 65W, Input: 100~240V AC 50/60Hz universal
Dimensions (W x D x H)
29.0 x 12.1 x 2.75 ~ 5.09 cm (11.42" x 4.76" x 1.08" ~ 2.00")
Security
Microsoft Pluton security processor
Built-in Fingerprint Sensor
